Description
Product Benefits
- The introduction of the vertical lift levers, housed and anchored securely between the steel lock-case and lock-cap, restricts a forced entry.
- The lever housing prevents a lever pack collapse against bolt-head pressure.
- The cruciform wall design protects the gating-stump and shrouds the lever pack from interference.
- The centralised bolt-tail protects against a gate-drilling intrusion, and makes it difficult to pick the bottom (3) levers.
- The centralised bolt-tail also enables the reverse handing of the lock in the field.
- The consistent contoured belly profiles on the levers resist optical/impression intrusion techniques.
- Ball bearings fitted into the scew-bearers makes penetration by drill very difficult.
Technical Specifications
- (6) pick resistant levers.
- (1,000,000) possible keycode combinations.
- (2) single-bitted steel keys are provided.
- (10) keylengths are available.
- Keylengths are measured by the distance between the bitt-and-bow of the key.
- Keylengths start from the 30mm (R30) key through to the 180mm (R180) key.
- Keycodes are read from the tip of the key to the ROSS embossed keybow.
Alternative Lock Options
- A ‘Latch Bolt’ (Slam-Bolt) lock version.
- A ‘Bolt-On’ lock version.
- A restricted profile ‘Wave’ key version.
- An (8) lever lock option.
